Setting Up OIDC Authentication for Kibana with Search Guard FLX

Configure Keycloak Authentication for Kibana with Search Guard FLX

Prerequisites

Elasticsearch cluster with the
Search Guard FLX
plugin installed
Kibana with the matching Search Guard Kibana plugin version
sgctl available for uploading Search Guard configuration
A running
Keycloak
server
Valid TLS certificates so Kibana and Elasticsearch can trust Keycloak

Create a Keycloak Client for Kibana

Log in to the
Keycloak Admin Console
.
Choose or create a
realm
(e.g. your-realm).
Go to
Clients → Create
and set:
Client ID:
my-kibana-client (or another name)
Client Type:
openid-connect
Client Authentication:
ON
(confidential client)
Standard Flow Enabled:
ON
Set the Root URL to your Kibana URL:
(e.g., https://kibana.example.com:5601/)
Valid Redirect URIs:
https://kibana.example.com:5601/auth/oidc/login (replace with your public Kibana URL; avoid wildcards in production)
Save and copy the
client secret
from the Credentials tab.

Configure Search Guard Backend Authentication (sg_authc.yml)

auth_domains:
  - type: basic/internal_users_db

./sgctl.sh connect --cluster https://elasticsearch:9200 --user admin --password  <admin-password> --ca-cert /path/to/ca.pem
./sgctl.sh update-config /path/to/sg_authc.yml

Configure Kibana Frontend OIDC (sg_frontend_authc.yml)

# sg_frontend_authc.yml
default:
  auth_domains:
    - type: oidc
      id: keycloak_oidc
      label: "Keycloak SSO"

      oidc.client_id: "<my-kibana-client>"
      oidc.client_secret: "<client-secret-from-keycloak>"

      oidc.idp.openid_configuration_url: "https://keycloak.example.com/realms/your-realm/.well-known/openid-configuration"

      oidc.get_user_info: true
      oidc.use_pkce: true

      # Map roles based on how they appear in your token
      # If you added the optional mapper:
      user_mapping.roles.from_comma_separated_string: "oidc_id_token.roles"
      # Or map directly from default Keycloak paths:
      # user_mapping.roles.from: "oidc_id_token.realm_access.roles"
      # user_mapping.roles.from: "oidc_user_info.resource_access.kibana.roles"

    - type: basic
      label: "Local login (fallback)"

./sgctl.sh update-config /path/to/sg_frontend_authc.yml

Configure Kibana (kibana.yml)

server.name: kibana
server.host: "0.0.0.0"
server.publicBaseUrl: "https://kibana.example.com:5601"

elasticsearch.hosts: ["https://elasticsearch:9200"]
elasticsearch.username: "kibanaserver"
elasticsearch.password: "<kibanaserver-password>"
elasticsearch.ssl.verificationMode: none
elasticsearch.requestHeadersWhitelist: ["Authorization", "sgtenant"]

searchguard.cookie.password: "<random-32+char-secret>"
searchguard.cookie.isSameSite: None
searchguard.cookie.secure: true

Map Roles (sg_roles_mapping.yml)

sg_kibana_user:
  backend_roles:
    - "kibana_user"

sg_kibana_admin:
  backend_roles:
    - "kibana_admin"

./sgctl.sh update-config /path/to/sg_roles_mapping.yml

Restart and Test

Restart Elasticsearch (if you updated its configs) and Kibana.
Browse to https://kibana.example.com.
You should be redirected to Keycloak.
Log in with a user who has the kibana_user or kibana_admin role.
You’ll be redirected back to Kibana with the appropriate privileges.

Troubleshooting Checklist

Check Elasticsearch and Kibana logs for error messages
Verify that all URLs and client credentials are correct
Ensure that the Keycloak roles are correctly mapped to Search Guard roles
Check that the Search Guard FLX plugin is properly installed and configured in both Elasticsearch and Kibana
Check our documentation and Kibana Troubleshooting.

Security Best Practices

Always use
confidential clients
and store secrets securely.
Limit valid redirect URIs to exact values—avoid wildcards.
Keep TLS enabled and provide trusted CA certificates instead of disabling verification.
Enable oidc.use_pkce: true for additional protection.
Rotate client secrets regularly and monitor logs for authentication anomalies.

Conclusion

REST API auth (Kibana server user) lives in sg_authc.yml.
Kibana single sign-on lives in sg_frontend_authc.yml.
Keycloak roles map to Search Guard roles in sg_roles_mapping.yml.
