From X-Pack to Search Guard: Part 2 - Roles and Permissions

CEO / Founder

This article demonstrates how to migrate custom roles from X-Pack Security to Search Guard, enabling you to maintain your access control structure during the transition between these security solutions.

X-Pack Roles

In X-Pack, privileges are pre-defined sets of actions for operating on indices or the Elasticsearch cluster. For example, write is an index-level privilege that grants write operations on documents, while the cluster-level privilege create_snapshot allows creating snapshots and listing existing repositories. Privileges represent the lowest granularity in X-Pack Security. You cannot modify pre-defined privileges or work directly at the action level.

Permissions are created by combining one or more privileges with a secured resource (typically an index or index pattern). For example, a permission might grant read and write privileges to all indices matching the my-index* pattern.

A role, which can be assigned to users through role mapping, is a named set of permissions:

{
  "cluster":[
    "all"
  ],
  "indices":[
    {
      "names":[
        "index*",
        "some"
      ],
      "privileges":[
        "all"
      ],
      "allow_restricted_indices":false
    },
    {
      "names":[
        "index1*",
        "some1"
      ],
      "privileges":[
        "all"
      ],
      "allow_restricted_indices":false
    },
    {
      "names":[
        "index2*",
        "some1"
      ],
      "privileges":[
        "read"
      ],
      "allow_restricted_indices":false
    }
  ]
}

Roles and role mappings can be retrieved through the X-Pack Security APIs or by querying the .security index directly.

Search Guard Roles

In Search Guard, similar concepts exist, but with key differences in terminology and capabilities. Unlike X-Pack Security, Search Guard allows you to define permissions at the action level. What X-Pack calls "privileges" are "action groups" in Search Guard:

X-Pack Security	Search Guard	Remarks
action	action	Directly configurable in Search Guard
privilege	action group
permission	permission
role	role
role mapping	roles mapping

A role in Search Guard looks like this:

{
  "cluster_permissions":[
    "SGS_CLUSTER_ALL"
  ],
  "index_permissions":[
    {
      "index_patterns":[
        "index*",
        "some"
      ],
      "allowed_actions":[
        "SGS_INDICES_ALL"
      ]
    },
    {
      "index_patterns":[
        "index1*",
        "some1"
      ],
      "allowed_actions":[
        "SGS_INDICES_ALL"
      ]
    },
    {
      "index_patterns":[
        "index2*",
        "some1"
      ],
      "allowed_actions":[
        "SGS_READ"
      ]
    }
  ]
}

Migrating Roles

To migrate custom roles, we need to retrieve them from Elasticsearch, transform their structure to match Search Guard's format, map X-Pack privileges to Search Guard action groups, and import them into Search Guard. We'll demonstrate a practical approach using command-line tools.

For processing JSON on the command line, we recommend installing jq and using the bash shell for the commands below.

First, retrieve all your custom roles from Elasticsearch:

curl -Ss -u "elastic:<password>" localhost:9200/.security/_search?pretty\&size=1000\&q=type:role

Use jq to transform the roles into a format closer to Search Guard's requirements:

curl -Ss -u "elastic:<password>" localhost:9200/.security/_search?pretty\&size=1000\&q=type:role | jq '.hits.hits[] | { _rolename: ._id | split("-")[1], cluster_permissions: ._source.cluster, index_permissions: ._source.indices } | del(.index_permissions[].allow_restricted_indices)'

This produces output like:

{
  "_rolename": "my_custom_role",
  "cluster_permissions": [
    "all"
  ],
  "index_permissions": [
    {
      "names": [
        "index*",
        "some"
      ],
      "privileges": [
        "all"
      ]
    },
    {
      "names": [
        "index1*",
        "some1"
      ],
      "privileges": [
        "all"
      ]
    },
    {
      "names": [
        "index2*",
        "some1"
      ],
      "privileges": [
        "read"
      ]
    }
  ]
}

Now, we need to rename fields and map privilege names to Search Guard action groups. Let's enhance our approach with a little bash script:

#bin/bash

# Initialize an empty JSON object
echo "{}" > sg_roles.json

curl -k -Ss -u "elastic:4JidJvyIIcbo2INER2Wh" https://localhost:9200/.security/_search?pretty\&size=1000\&q=type:role | jq '[.hits.hits[] | { _rolename: ._id | split("-")[1], cluster_permissions: ._source.cluster, index_permissions: ._source.indices } | del(.index_permissions[].allow_restricted_indices) | del(.index_permissions[].allow_restricted_indices)]' > roles_mig_tmp.json

# Loop roles_mig.tmp (every row is a role)
for row in $(cat "roles_mig_tmp.json" | jq -r '.[] | @base64'); do

   # Count index permissions in this role
   index_permissions_count=$(echo ${row} | base64 --decode | jq  '.index_permissions | length')
   let index_permissions_count=index_permissions_count-1

   JQ_NAME_FIX=""
   for i in $(eval echo "{0..$index_permissions_count}")
   do
     # Rename .names to .index_patterns and .privileges to .allowed_actions
     JQ_NAME_FIX=".index_permissions[$i].index_patterns=.index_permissions[$i].names | $JQ_NAME_FIX "
     JQ_NAME_FIX=".index_permissions[$i].allowed_actions=.index_permissions[$i].privileges | $JQ_NAME_FIX "
   done

   # Extract the role name
   ROLE_NAME=$(echo ${row} | base64 --decode | jq  '._rolename' | tr -d '"')

   # Remove fields we no longer need
   JSON="$(echo ${row} | base64 --decode | jq  "$JQ_NAME_FIX del(.index_permissions[].names) | del(.index_permissions[].privileges) | del(._rolename)")"

  # Append the role to the final JSON object
  tmp=$(mktemp)
  jq --arg key "$ROLE_NAME" --argjson val "$JSON" '. + {($key): $val}' sg_roles.json > "$tmp" && mv "$tmp" sg_roles.json

done

Mapping Privileges to Action Groups

Next, we need to replace the privileges from the original X-Pack role definition with Search Guard Action Groups. Open the sg_roles.json file that was generated above and search and replace the privileges in the file.

The following tables map common X-Pack privileges to Search Guard action groups. Although some names may sound similar, the granted permissions may differ slightly. Review each privilege to ensure the corresponding action group doesn't grant excessive permissions.

If no default action group meets your needs, you can combine multiple action groups or define custom action groups.

Cluster Privileges

X-Pack Security privilege	Search Guard action group
all	SGS_CLUSTER_ALL
createsnapshot \| SGS\MANAGE_SNAPSHOTS
manageindextemplates	SGS_CLUSTER_MANAGE_INDEX_TEMPLATES
manageingestpipelines	SGS_CLUSTER_MANAGE_PIPELINES
monitor	SGS_CLUSTER_MONITOR

Indices Privileges

X-Pack Security privilege	Search Guard action group
all	SGS_INDICES_ALL
create	SGS_CREATE_INDEX
createindex \| SGS\CREATE_INDEX
delete	SGS_DELETE
index	SGS_WRITE
manage	SGS_MANAGE
monitor	SGS_INDICES_MONITOR
read	SGS_READ
write	SGS_WRITE

Using sgctl to connect to our Search Guard secured cluster

In the following steps, we will use the Search Guard Control Tool (sgctl) to connect to the cluster and upload the user configuration. First, download the latest version of sgctl from our Maven repository:

https://maven.search-guard.com/search-guard-flx-release/com/floragunn/sgctl/

Download the ZIP file und unzip it in a directory of your choice. Next, we connect to Search Guard by specifying the Root CA and the certificate and key of our admin certificate. If you have used the Search Guard Demo Installer, the command looks like:

./sgctl.sh connect localhost --ca-cert /path/to/elasitcsearch/config/root-ca.pem --cert /path/to/elasitcsearch/config/kirk.pem --key /path/to/elasitcsearch/config/kirk-key.pem

If your certificates are named differently or stored elsewhere, update the path settings accordingly. If successful, the output looks like:

Successfully connected to cluster mycluster (localhost) as user CN=kirk,OU=client,O=client,L=test,C=de

Upload the roles configuration

The last step is to simply upload the roles definition to Search Guard:

./sgctl.sh update-config /path/to/sg_roles.json

Which should create an output like this:

Successfully connected to cluster mycluster (localhost) as user CN=kirk,OU=client,O=client,L=test,C=de
Configuration has been updated

Articles in this series

From X-Pack to Search Guard: Part 1 - TLS Setup

From X-Pack to Search Guard: Part 2 - Roles and Permissions (This article).

Coming Soon: * From X-Pack to Search Guard: Part 3 - Users * From X-Pack to Search Guard: Part 4 - Document- and Field-Level Security
